Robust High Voltage Battery Management System
Advanced BMS providing cell balancing, thermal management, and state of charge estimation for high voltage battery packs in electric vehicles, renewable energy storage, and high power applications.
Product Overview
The High Voltage Battery Management System (HV BMS) is an advanced solution designed for managing high voltage battery packs. It ensures optimal performance, safety, and longevity through comprehensive monitoring of voltage, current, temperature, and state of charge. The system prevents hazards like overcharging, over-discharging, short circuits, and thermal runaway.
Key Features
- HV Battery Safety Management for optimal protection and reliability
- Advanced High Voltage Battery Supervisory System for real-time monitoring
- Comprehensive High Voltage Energy Management System integration
- Accurate cell voltage and temperature measurement
- Overcharge, over-discharge, and short circuit protection
- State of Charge (SOC) and State of Health (SOH) estimation
- Fault detection and diagnostic capabilities
- Balancing of battery cells to maximize lifespan and performance
- Communication interfaces for seamless integration with vehicle control units
- Robust design suitable for high voltage applications
- Data logging and event recording for maintenance and analysis
- Scalable architecture to support different battery pack sizes
Technical Specifications
| Product Name | High Voltage Battery Supervisory System (HV BMS) |
|---|
| Model | HV Battery Control Module |
|---|
| Operating Voltage | 200V - 800V DC |
|---|
| Battery Cell Count | Up to 96 series cells |
|---|
| Current Measurement Range | ±500A |
|---|
| Communication Interface | CAN 2.0B, UART |
|---|
| Operating Temperature | -40°C to 85°C |
|---|
| Protection Features | Overvoltage, Undervoltage, Overcurrent, Short Circuit, Temperature Protection |
|---|
| Dimensions | 250mm x 180mm x 70mm |
|---|
| Weight | 1.5 kg |
|---|
| Accuracy | Voltage ±0.5%, Current ±1% |
|---|
| Certification | ISO 26262, CE, RoHS |
|---|
| Application | High Voltage Battery Supervisory System for electric vehicles and energy storage systems |
|---|
Applications
The GCE RBMS07S23-125A480V High Voltage BMS Controller provides advanced battery safety management for electric vehicles, renewable energy storage systems, industrial equipment, and other high voltage applications. It ensures safety and longevity of battery packs through continuous monitoring and precise management.
Support and Services
Our comprehensive support includes system integration assistance, configuration, firmware updates, and troubleshooting. We provide technical consultation, system calibration, performance testing, and custom software development to ensure optimal operation and compliance with industry standards.
Packaging and Shipping
Each HV BMS unit is securely packaged in anti-static bags with custom foam inserts within sturdy cardboard boxes. Shipping options include standard, expedited, and express delivery with tracking. International shipments include complete customs documentation.
Frequently Asked Questions
- What is the brand and model number?
Brand: GCE, Model: RBMS07S23-125A480V
- What certifications does this HV BMS have?
CE certified, meeting European safety and quality standards
- What is the minimum order quantity and pricing?
Minimum order: 2 units. Pricing is negotiable
- What are the payment terms and delivery time?
Payment: T/T or L/C. Delivery: 20-25 days after order confirmation
- How is the product packaged and what is the supply capacity?
Packaging: Carton. Supply capacity: 1000 pieces per month
Contact Information:
For detailed quotations and orders, please contact: jeffreyth@hngce.com
Product Images
